How To Measure Your Door Opening For PVC Strip Curtains

Short answer: do not send only "standard size" or a doorway photo. For a useful PVC strip curtain quotation, send the clear opening width, clear opening height, mounting area, traffic type, use case, quantity, location, and whether you need strips only or a complete set with hanger and rail.

PVC Strip Curtains PH uses those details to check the right product family, strip size, overlap direction, and hardware scope before preparing a quotation. A small missing detail can change the recommendation, especially for cold rooms, freezer areas, loading bays, food areas, and busy warehouse openings.

1. Start With The Opening, Not The Old Curtain

Start with the actual doorway or opening where the PVC curtain will be installed. Do not measure only the old strip curtain if it is already stretched, damaged, curled, or cut too short.

This is the first thing we check because the curtain should fit the doorway, not copy a worn curtain that may already be wrong. Write the details in this order before sending an inquiry:

1. Clear opening width: left to right.
2. Clear opening height: floor to top opening or fixing point.
3. Number of openings: one doorway, several doors, or a partition run.
4. Traffic type: people, carts, pallet jacks, forklifts, or mixed use.
5. Use case and location: warehouse, cold room, freezer room, food area, loading bay, kitchen, partition, and delivery area.

For cold rooms or freezer-related openings, also include the target temperature or current operating condition. That tells us whether a polar/freezer PVC strip curtain should be considered instead of a general-purpose PVC strip.

2. Measure The Width In Three Spots

Measure the opening from the left inside edge to the right inside edge. If the curtain will sit on the face of the wall instead of inside the opening, note that too, because the final coverage may need allowance outside the clear opening.

For many doorways, one width measurement is not enough. Measure at the top, middle, and bottom, especially if the frame is old, uneven, or roughly finished. Send the three numbers if they differ.

We use the width to check the curtain coverage and discuss the likely strip width and overlap. Do not worry if you do not know the exact overlap yet. The important first step is to send the real opening width and describe what passes through the doorway.

Example:

Door width top: 2.38m
Door width middle: 2.40m
Door width bottom: 2.39m
Opening type: warehouse service door
Traffic: carts and people

3. Measure The Height And Mounting Surface

Measure from the floor to the top of the opening or to the place where the rail can be mounted. If the floor slopes, has a ramp, or has uneven concrete, measure both sides and include a photo.

The height helps us check the strip length and the bottom clearance. The mounting surface helps us check whether the inquiry is likely to be strips only, replacement strips, or a complete set with hanger and rail.

Also mention anything around the opening that may affect the quote, such as floor drains, ramps, uneven concrete, pipes, rollers, existing doors, old rail, or old hanger plates.

Example:

Door height: 2.1m
Mounting area: wall face above opening
Floor condition: slight ramp
Existing hardware: none

4. Tell Us What Happens Through The Door

The same doorway size can need a different curtain depending on the use case. A stockroom door, food processing entrance, freezer room, and loading bay should not be treated as one generic PVC curtain request.

Include the doorway activity in plain words:

• People only: easier access may matter more.
• Carts or pallet jacks: strip durability and ribbed options may be discussed.
• Forklift traffic: doorway size, strip width, thickness, and overlap need closer checking.
• Cold room or freezer area: send the target temperature or current operating condition.
• Food area or insect-sensitive doorway: yellow anti-insect PVC may be considered, depending on the use case.
• Replacement work: send photos of existing strips, rail, and hanger plates.

This is how PVC Strip Curtains PH narrows the product discussion. We may start from clear/plain, clear/ribbed, yellow/plain, yellow/ribbed, polar/freezer grade, magnetic, or complete-set options depending on the details you send.

5. Take Photos That Show The Quotation Issue

A photo is not always required, but it can prevent mistakes. Take one straight photo of the whole doorway and one closer photo of the top mounting area.

If you already have a PVC strip curtain, also send a photo of the existing rail, hanger plates, and one old strip if possible. That helps us check whether you are asking for replacement strips only or a fuller hardware quote.

Good photos show:

• The full doorway from floor to top.
• The left and right sides of the frame.
• The top mounting area.
• Any old curtain rail or hanger plates.
• Obstructions such as pipes, rollers, drains, or uneven walls.

6. Decide The Quote Scope: Strips Only Or Complete Set

Before quoting, it helps to say what you need supplied. If you are not sure, write "recommendation needed" and send photos.

Use this format:

Do not assume every quotation includes the same hardware or site work. Ask for the included items to be listed clearly, especially if you need hanger, rail, fasteners, delivery, or installation-related scope.

7. Send The Quote Details In One Message

Use this copy-ready format when you message PVC Strip Curtains PH:

Door opening: 2.4m width x 2.1m height
Width checked at: top / middle / bottom
Quantity: 1 doorway
Curtain type: clear ribbed PVC, or recommendation needed
Traffic: people and carts
Use case: warehouse doorway
Location: Laguna
Existing hardware: none
Need: strips only or complete set with hanger and rail
Photos: full doorway and top mounting area attached

If you are not sure about the curtain type, send the opening size and describe the doorway. The team can check the practical starting point instead of asking you to choose from product names too early.

8. What Happens After You Send The Details

When PVC Strip Curtains PH receives a clearer inquiry, the team can review the project in a more useful order:

1. Check the door opening size and number of openings.
2. Check the environment: warehouse, loading bay, cold room, freezer, food area, kitchen, or partition.
3. Check the traffic type: people, carts, pallet jacks, forklifts, or mixed traffic.
4. Check whether the likely supply is strips only, replacement strips, or a complete set with hanger and rail.
5. Check the product family and sizing direction before preparing the quotation.

If an important detail is missing, the team may ask a follow-up question before quoting. That is normal. It is better to confirm the doorway and use case first than to quote the wrong curtain, wrong strip size, or incomplete hardware scope.

PVCPH Quote Check

For this article, connect the advice to the actual doorway before requesting price. The team should be able to check measurement accuracy, top mounting area, and whether the request is strips only or a complete set from the first message instead of guessing from the article topic alone. When the details are ready, send them through the PVCPH quotation page.

After measuring, compare the PVC strip curtain products, use the PVC curtain quotation checklist, and review the 2mm vs 3mm thickness article if traffic may affect the recommendation.

PVCPH should be able to review:

• Opening size: width x height of the clear doorway opening.
• Traffic and environment: people, carts, forklifts, cold-room use, food-area use, or general warehouse movement.
• Product direction: clear, ribbed, yellow, polar/freezer, magnetic, replacement strips, or complete set with hanger and rail when needed.
• Location and photos: delivery area plus full doorway, top mounting area, and existing hardware photos when available.

FAQ

Should I measure in meters or millimeters?

Either is fine if the measurement is clear. For formal RFQs, meters are common for doorway size, while product strip widths and thicknesses are usually listed in millimeters.

What if I have more than one door?

List each opening separately. For example: Door 1, Door 2, Door 3. Include width x height for each one.

Do I need to choose the exact overlap?

Not at the first inquiry stage. Send the opening size, use case, and traffic type. The overlap recommendation can be checked during quotation.

Can I just send a photo and ask for a price?

A photo helps, but it should not replace the measurement. Send width x height with the photo so the team can check size, product type, and hardware scope more accurately.

What if I do not know the PVC curtain type?

That is okay. Say recommendation needed and describe the use case. For example: warehouse doorway with carts, freezer entrance, restaurant stockroom, food-area doorway, or loading bay.
